A hose clamp is a mechanical device used to fasten hoses to pipe fittings. It is widely applied in automobiles, industrial pipelines, household appliances, and hydraulic systems. Its core function is to ensure fluid tightness, preventing leakage or disconnection.
| Item |
Standard Value |
| Material |
Stainless steel (304/316), galvanized carbon steel |
| Operating Temperature |
-30°C ~ +150°C |
| Pressure - Bearing Range |
≤1.6MPa (static) |
| Applicable Pipe Diameter |
Φ10mm~Φ200mm (customizable) |
- Select Material According to the Environment:
- In humid/corrosive environments: 316 stainless steel is preferred.
- For general industrial applications: 304 stainless steel or galvanized carbon steel can be used.
- Match the Model According to Pressure:
- For low - pressure pipelines (<0.5MPa): Worm - drive hose clamps are recommended (low cost).
- In high - pressure scenarios: Double - bolt heavy - duty hose clamps should be selected.
- Automotive Industry: Used for fixing engine cooling pipelines (needs to pass vibration tests).
- Food Machinery: Non - plated stainless - steel hose clamps are adopted, meeting FDA standards.
- Chemical Pipelines: Paired with PTFE gaskets for acid and alkali corrosion resistance.
- Water - cooling Industry: Paired with quick - connect fittings.
